Introduction

The JET-5601AH DDR4 288 Extender is designed for testing of motherboard.

It is used to protect the DDR4 Memory module during testing.

For the motherboard testing, user needs plug the DDR4 Memory module into DDR4 socket of JET-5601AH firstly.

And plug its combination into DDR4 socket of motherboard during motherboard testing.

Feature

Design：4 Layers PCB design.

Compatibility：Compliant with JEDEC Specification MO-309C.

Frequency over 2133 MHz.

Over current protect on the SPD device.
