Introduction

• The JET-5623E DDR4 240 Extender is designed for testing of memory module maker.
•  It is used to protect the DDR4 Memory module during testing.
•  For DDR4 Memory module testing, user needs plug the JET-5623E into tested machine (such as motherboard or DDR4 Memory module testing equipment) firstly. And plug the DDR4 Memory Module into socket of JET-5623E during module testing

Feature

• DesignΚ4 Layers PCB design.
•  CompatibilityΚCompliant with JEDEC Specification MO-309C.
•  Frequency over 2133 MHz.
•  Over current protect on the SPD device
