B1908B-DB19 (SD to Micro SD FPC Extender)

Introduction:

B1908B-DB19, SD to Micro SD card Extender is a debug or test tool with 1.8V SD Card power supply support. Design the FPC cable for flexible use.
B1912B + DB19 allows a SD Card to be extended from the micro SD slot.
It’s especially designed to save valuable labor and time in the production environment. The MicroSD extender is designed to minimize the signal degradation effects of the extender by proven design techniques. It’s also a powerful tool for engineers, or use for mobile phone micro SD test protection.

Documents Download
Brief	Taiwan	Taiwan 2 Mirror	China Mirror
Dimension	Taiwan	Taiwan 2 Mirror	China Mirror
3D Model	Taiwan	Taiwan 2 Mirror	China Mirror
Schematic	Taiwan	Taiwan 2 Mirror	China Mirror
SD Extender comparison	Taiwan	Taiwan 2 Mirror	China Mirror
Selection Guide	Tawan	Taiwan 2 Mirror	China Mirror
