**Please see JET-5608AK** (DDR4 SODIMM to DIMM Adapter with Metal Guide)

Introduction

The JET-5608AA DDR4 SODIMM to DIMM is designed to test the newest DDR4 SODIMM modules on desktop setting. Simply plug the JET-5608AA into the DDR4 DIMM socket on the system or tester. Then insert the DDR4 SODIMM module onto the JET-5608AA for testing or burning-in.

Feature:

- Patented design

- Frequency: Over 2133Mhz

- Design: 4 Layers PCB Design

- Compatibility: Compliant with JEDEC Specification

- Lifespan: Under normal operation use, the lifespan of this DDR4 SODIMM adapter could exceed 600 insertions

- Protection: Over Current Protection on SPD device

- Support EEPROM (SPD) device on protector card.

   JP2: Selecting EEPROM (SPD) device location

   1-2 short: Select EEPROM (SPD) device on adapter

   2-3 short: Select EEPROM (SPD) device on the Memory Module (DUT)
