Introduction

• The JET-5661AC DDR5 UDIMM Extender is designed to test DDR5 Unbuffered DIMM memory modules.
• It is used to protect the DDR5 RDIMM Memory Modules and its sockets
• For DDR5 RDIMM Memory Module testing, user first plugs in the JET-5661AC onto the tested system (such as motherboard or DDR5 UDIMM Memory module testing equipment). Then inserts the DDR5 UDIMM Memory Module onto the socket of JET-5661AC before proceeding to run the memory module testing.

Feature

• Design: 4 Layers PCB Board
• Compatibility: Compliant with JEDEC Specification MO-329C
• Frequency over 4800Mhz
