Introduction

 ◼ The JET-5684EA DDR5 UDIMM Extender is designed for testing of memory module maker.

 ◼ It is used to protect the DDR5 UDIMM Memory module during testing.

 ◼ For DDR5 UDIMM Memory module testing, user needs plug the JET-5684EA into tested machine (such as motherboard or DDR5 UDIMM Memory module testing equipment) firstly. And plug the DDR5 UDIMM Memory Module into socket of JET-5684EA during module testing.

 Feature

 ◼ Design： 4 Layers PCB design.

 ◼ Compatibility： Compliant with JEDEC Specification MO-329C.

 ◼ Frequency over 6400 MHz.
