Introduction

• The JET-5684EE DDR5 UDIMM Extender is designed for testing of memory module maker.
•  It is used to protect the DDR5 UDIMM Memory module during testing.
•  For DDR5 UDIMM Memory module testing, user needs plug the JET-5684EE into tested machine (such as motherboard or DDR5 UDIMM Memory module testing equipment) firstly. And plug the DDR5 UDIMM Memory Module into socket of JET-5684EE during module testing.

Feature

• Design：4 Layers PCB design.
•  Compatibility：Compliant with JEDEC Specification MO-329C.
•  Frequency over 6400 MHz
